Competent insulation of a wooden house outside: do it yourself
Thermal insulation of houses is carried out not only to reduce heating costs and reduce heat loss. High-quality insulation of a wooden house from the outside allows you to keep a comfortable coolness in the premises in the heat. This reduces the need for air conditioners and, accordingly, electricity consumption. It has been proven that external thermal insulation is much more effective than internal one.
Wooden houses also need insulationand
The content of the article [Hide]
We decide how and what to insulate a wooden house
Thermal insulation of a wooden structure can be done in two ways:
Given the high cost, the use of lining is impractical
The use of the first option can significantly reduce costs during the heating period. For this, lining is often used, the combination of the elements of which creates an integral canvas. But such material is prone to cracking and deformation. In addition, it is difficult to install, and also has a rather high cost.
Adding insulation increases the functionality of the siding
The most common options for thermal insulation of a house, which protects from cold and bad weather, is siding, equipped with an additional basis for insulation. The effectiveness of the material will increase significantly if a layer of insulation is placed under it.
Additional base improves the quality of thermal insulation
Review of quality home insulation: how to choose the right insulation
Modern manufacturers offer a huge selection of all kinds of materials that allow you to insulate external walls:
Insulation for the outer walls of the house can be different
Related article:
Loose heat insulators for insulating a wooden house outside
They are environmentally friendly, since they are not able to emit toxic substances during operation and are made from natural materials:
The characteristics of these materials for external insulation of wooden houses can be found in the table below.
Table 1. Characteristics of materials for thermal insulation of wooden houses
| Picture | Insulation type | Water vapor permeability, Mg / (m * h * Pa) | Thermal conductivity, W / (m * C) | Density of filling, kg / m3 |
|---|---|---|---|---|
 | Vermiculite crushed stone | 0,28 | 0,16 | 251 |
 | Expanded clay gravel | 0,28 | 0,13 | 200 |
| 0,22 | 0,22 | 801 | ||
 | Vermiculite sand | 0,4 | 0,09 | 101 |
 | Perlite crushed stone | 0,28 | 0,13 | 200 |
As you can see, the thermal conductivity of bulk heat insulators is practically the same, the difference between them is only in price. All of them have excellent steam conductivity, which contributes to the free exit of moisture from the walls. In addition to steam conductivity and high environmental friendliness, these materials have the following qualities:
The disadvantage of bulk materials is poor thermal conductivity, which provides for the insulation of houses in regions with a warm climate.
Mineral wool
The material is the result of processing waste from metallurgy or rocks, such as dolomite or basalt. It differs in:
The effectiveness of mineral wool will increase in combination with siding
For thermal insulation, roll material or basalt slabs are used. Such insulation is ideal for brick, gas and foam concrete, as well as wooden buildings.
It is much more convenient to use slab mineral wool for external walls than roll
You can work with the material at any temperature, which is very convenient for insulating external walls. The most common application is to insulate wooden houses outside with mineral wool for siding.
Covering seams with mineral wool increases moisture
Styrofoam (expanded polystyrene)
Refers to modern polymer insulation, and is widely used in construction. This material is characterized by:
The thermal insulation qualities of expanded polystyrene depend on its density
It is also worth noting the low weight of the material, which reduces transport costs and installation costs. Thanks to this quality, the walls are not stressed, which eliminates the need to strengthen the foundation.
The lightness of the foam allows you to do the work yourself
Another advantage of the material is its low cost, which allows external walls to be insulated. In this video, one person does the insulation of the house outside with foam plastic with his own hands due to the lightness of the material:
Extruded polystyrene foam
An innovative heat-insulating material, in the manufacture of which nano-particles of graphite are used, which contribute to an increase in energy saving and product strength. The thermal conductivity of polystyrene foam is 0.029-0.032 W per each m2.
The characteristics of expanded polystyrene speak for themselves
In addition, the material is resistant to chemicals and mold, has high sound insulation and is not afraid of rodents. These qualities make it possible to use penoplex for external insulation of a wooden house.
A competently performed work guarantees high-quality thermal insulation
Related article:
Polyurethane foam
The material has a cellular foam structure filled with air. This significantly reduces the coefficient of thermal conductivity, which is a maximum of 0.042 W per m2.
Insulation with polyurethane foam requires special skills
Due to the high adhesion of the material to any surfaces, an airtight coating is formed, which guarantees excellent hydro and vapor barrier. High elasticity, combined with seamless technology, make it indispensable for insulating frame walls and blown thermal insulation, as well as for complex configurations. The insulation is applied at any temperature, and the durability reaches 30 years.
The insulation tightly clogs all the cracks, but you can't do without special equipment.
The disadvantages include the too high cost of polyurethane foam, as well as the need to use special equipment.
We calculate the thickness of the insulation
In order for the insulation of a wooden house from the outside to be effective, it is necessary not only to choose a heat-insulating material, but also to correctly calculate the required thickness, which will depend on the ability to resist heat.
Recommended insulation thickness, taking into account winter temperatures
This is the opposite indicator of thermal conductivity, the coefficient of which is indicated by the manufacturer on the packages. To calculate the coefficient of resistance to heat transfer, there is a formula:
R = d / k, Where
d - corresponds to the thickness of the material, and k - its thermal conductivity. The higher the value obtained, the higher the thermal insulation efficiency will be.
External wall insulation significantly reduces heat loss
Insulation allows you to reduce the loss of heat energy through floors, walls, roofs. The lack of thickness of the insulation can lead to a displacement of the dew point inside the room, which leads to the formation of condensation, provoking the appearance of fungi, as well as dampness. Too large a layer of material is not capable of leading to significant temperature changes, however, it forces significant financial costs, which is irrational. To save money by providing optimal conditions, it is necessary to correctly calculate the thickness of the insulation.
Insulation of the foundation will help reduce heat loss
Calculator for calculating the thickness of the insulation of the walls of a wooden house
Schematic map for determining the required value of the resistance to heat transfer
Related article:
Conclusion
Decide what is better insulate the wall outside the house, you should own. However, when choosing insulating materials, you should definitely take into account the following factors:
Polyurethane foam insulation performance equal to those of a brick wall thickness of 1 meter
All materials have different features, that does not give a clear answer, which one is better. The choice will depend on the characteristics of the building, as well as the quality and wall thickness. Each of these heaters has a right to exist and is able to effect with proper application.
Video: wooden house - the sheathing, and how warm
